Fox Racing Air Shocks 2" Coil Over Body 17.35" Stroke 1-1/4" Shaft Emulsion Shock Without Reservoir
Invented by Bob Fox in 1974, air shocks offer infinite ride height settings with simple nitrogen gas pressure changes in addition to their compression and rebound damping adjustability.
Factory Series 980-02-074 Dimensions:
Setup For Dual Spring Rate
38" Maximum Combined Total Spring Length
Typically Customers Purchase 18" Top Spring and 18" Bottom Spring
2.0" Diameter
17.35" Travel
43.630" Extended
26.290" Collapsed
1.25" Shaft Diameter
Shaft Material: 4130 Hollow Chromoly
1.25" Mounting Width Between Tabs
Uses 1/2" Shock Bolts
40 Compression / 90 Rebound Standard Valving
