Fox Racing Air Shocks 2" Coil Over Body 15.35" Stroke 1-1/4" Shaft Emulsion Shock Without Reservoir
Invented by Bob Fox in 1974, air shocks offer infinite ride height settings with simple nitrogen gas pressure changes in addition to their compression and rebound damping adjustability.
Factory Series 980-02-073 Dimensions:
Setup For Dual Spring Rate
35" Maximum Combined Total Spring Length
Typically Customers Purchase 16" Top Spring and 18" Bottom Spring
2.0" Diameter
15.35" Travel
39.630" Extended
24.290" Collapsed
1.25" Shaft Diameter
Shaft Material: 4130 Hollow Chromoly
1.25" Mounting Width Between Tabs
Uses 1/2" Shock Bolts
40 Compression / 90 Rebound Standard Valving
Factory Series 980-02-073 Dimensions:
Setup For Dual Spring Rate
35" Maximum Combined Total Spring Length
Typically Customers Purchase 16" Top Spring and 18" Bottom Spring
2.0" Diameter
15.35" Travel
39.630" Extended
24.290" Collapsed
1.25" Shaft Diameter
Shaft Material: 4130 Hollow Chromoly
1.25" Mounting Width Between Tabs
Uses 1/2" Shock Bolts
40 Compression / 90 Rebound Standard Valving
Invented by Bob Fox in 1974, air shocks offer infinite ride height settings with simple nitrogen gas pressure changes in addition to their compression and rebound damping adjustability.
Factory Series 980-02-073 Dimensions:
Setup For Dual Spring Rate
35" Maximum Combined Total Spring Length
Typically Customers Purchase 16" Top Spring and 18" Bottom Spring
2.0" Diameter
15.35" Travel
39.630" Extended
24.290" Collapsed
1.25" Shaft Diameter
Shaft Material: 4130 Hollow Chromoly
1.25" Mounting Width Between Tabs
Uses 1/2" Shock Bolts
40 Compression / 90 Rebound Standard Valving
Factory Series 980-02-073 Dimensions:
Setup For Dual Spring Rate
35" Maximum Combined Total Spring Length
Typically Customers Purchase 16" Top Spring and 18" Bottom Spring
2.0" Diameter
15.35" Travel
39.630" Extended
24.290" Collapsed
1.25" Shaft Diameter
Shaft Material: 4130 Hollow Chromoly
1.25" Mounting Width Between Tabs
Uses 1/2" Shock Bolts
40 Compression / 90 Rebound Standard Valving
