Silver Eibach 350 Pound 12" Tall Spring For 2.5" Diameter King, Sway-A-Way Or Fox Coil Over Shocks
If you're going to use this as an upper spring on a dual rate coil-over shock such as King, Fox, or Sway-A-Way, it's important to set the position of your crossover ring so the spring divider hits the cross over ring BEFORE the upper spring crushes itself (coil bind). See diagram below.


Eibach Part Number:
1200.300.0350s
1200-300-0350s
Length: 12 Inches / 305mm
Inside Diameter: 3 Inches / 76mm
Spring Rate: 350 lbs/inch - 6.25 kg/mm - 61 N/mm
Full Compressed Height: 4.41 Inches / 112mm
Travel: 7.59 Inches / 193mm
Load At Full Compression: 2657lbs / 11819N
Weight: 5.36lbs / 2.43kgs
1200.300.0350s
1200-300-0350s
Length: 12 Inches / 305mm
Inside Diameter: 3 Inches / 76mm
Spring Rate: 350 lbs/inch - 6.25 kg/mm - 61 N/mm
Full Compressed Height: 4.41 Inches / 112mm
Travel: 7.59 Inches / 193mm
Load At Full Compression: 2657lbs / 11819N
Weight: 5.36lbs / 2.43kgs


If you're going to use this as an upper spring on a dual rate coil-over shock such as King, Fox, or Sway-A-Way, it's important to set the position of your crossover ring so the spring divider hits the cross over ring BEFORE the upper spring crushes itself (coil bind). See diagram below.


Eibach Part Number:
1200.300.0350s
1200-300-0350s
Length: 12 Inches / 305mm
Inside Diameter: 3 Inches / 76mm
Spring Rate: 350 lbs/inch - 6.25 kg/mm - 61 N/mm
Full Compressed Height: 4.41 Inches / 112mm
Travel: 7.59 Inches / 193mm
Load At Full Compression: 2657lbs / 11819N
Weight: 5.36lbs / 2.43kgs
1200.300.0350s
1200-300-0350s
Length: 12 Inches / 305mm
Inside Diameter: 3 Inches / 76mm
Spring Rate: 350 lbs/inch - 6.25 kg/mm - 61 N/mm
Full Compressed Height: 4.41 Inches / 112mm
Travel: 7.59 Inches / 193mm
Load At Full Compression: 2657lbs / 11819N
Weight: 5.36lbs / 2.43kgs
