Silver Eibach 300 Pound 24" Tall Spring For 3" Diameter King, Sway-A-Way Or Fox Coil Over Shocks

Racegear WA

$916.49 $962.32
SKU: RGWA-ERS2400375300

On a dual rate coil-over shock such as King, Fox, or Sway-A-Way, it's important to set the position of your crossover ring so the spring divider hits the cross over ring BEFORE the upper spring crushes itself (coil bind). See diagram below.

Eibach Part Number:
2400.375.0300s
2400-375-0300s
Length: 24 Inches / 610mm
Inside Diameter: 3.75 Inches / 95mm
Spring Rate: 300 lbs/inch - 5.36 kg/mm - 53 N/mm
Full Compressed Height: 9.37 Inches / 238mm
Travel: 14.63 Inches / 372mm
Load At Full Compression: 4388lbs / 19519N
Weight: 18.73lbs / 8.5kgs

Eibach Spring Dimensions Example


How to setup dual rate springs on Fox shock crossover ring position
