Silver Eibach 300 Pound 20" Tall Spring For 3" Diameter King, Sway-A-Way Or Fox Coil Over Shocks
On a dual rate coil-over shock such as King, Fox, or Sway-A-Way, it's important to set the position of your crossover ring so the spring divider hits the cross over ring BEFORE the upper spring crushes itself (coil bind). See diagram below.
Eibach Part Number:
2000.375.0300s
2000-375-0300s
Length: 20 Inches / 508mm
Inside Diameter: 3.75 Inches / 95mm
Spring Rate: 300 lbs/inch - 5.36 kg/mm - 53 N/mm
Full Compressed Height: 7.36 Inches / 187mm
Travel: 12.64 Inches / 321mm
Load At Full Compression: 3792lbs / 16868N
Weight: 13.62lbs / 6.18kgs
2000.375.0300s
2000-375-0300s
Length: 20 Inches / 508mm
Inside Diameter: 3.75 Inches / 95mm
Spring Rate: 300 lbs/inch - 5.36 kg/mm - 53 N/mm
Full Compressed Height: 7.36 Inches / 187mm
Travel: 12.64 Inches / 321mm
Load At Full Compression: 3792lbs / 16868N
Weight: 13.62lbs / 6.18kgs
