Fox 2.5" Internal Bypass Shock Viton O-Ring Rebuild Kits For 7/8" Shaft With 2.5" Reservoir
Don't forget to purchase a shaft bullet (listed below). There's nothing worse than having to rebuild your shocks twice, simply because you tore a seal when you were reassembling your shock. This cheap tool saves a lot of headache and time spent in rebuilding your Fox shock absorber.
803-00-754-A IBP Kit Includes:
Shock Body Seals:
1 Wiper seal for the bearing cap
1 Wiper seal for the shaft bearing / shaft guide
1 Internal o-ring for the shaft bearing / shaft guide
1 External o-ring for the shaft bearing / shaft guide
2 Piggy back bridge to shock body o-rings
1 Body Cap O-Ring
1 Thin o-ring that goes underneath the shock piston wear band
1 Internal bypass tube o-ring
1 Bronze wear band for the shocks's piston
2.5" Reservoir Seals:
1 Soft wear band for the reservoir's piston
1 Thick o-ring for the reservoir's piston
2 O-rings for both end caps of the reservoir
Shock Body Seals:
2.5" Reservoir Seals:
Don't forget to purchase a shaft bullet (listed below). There's nothing worse than having to rebuild your shocks twice, simply because you tore a seal when you were reassembling your shock. This cheap tool saves a lot of headache and time spent in rebuilding your Fox shock absorber.
803-00-754-A IBP Kit Includes:
Shock Body Seals:
1 Wiper seal for the bearing cap
1 Wiper seal for the shaft bearing / shaft guide
1 Internal o-ring for the shaft bearing / shaft guide
1 External o-ring for the shaft bearing / shaft guide
2 Piggy back bridge to shock body o-rings
1 Body Cap O-Ring
1 Thin o-ring that goes underneath the shock piston wear band
1 Internal bypass tube o-ring
1 Bronze wear band for the shocks's piston
2.5" Reservoir Seals:
1 Soft wear band for the reservoir's piston
1 Thick o-ring for the reservoir's piston
2 O-rings for both end caps of the reservoir
Shock Body Seals:
2.5" Reservoir Seals:
